| 0805CS-181EGTS | |
|---|---|
| Part Number | 0805CS-181EGTS |
| Manufacturer | Delta Electronics/Components |
| Description | FIXED IND 180NH 400MA 640MOHM SM |
| Quantity Available | 335315 pcs new original in stock. Request Stock & Quotation |
| Datasheets | 0805CS-181EGTS.pdf |
| Download | 0805CS-181EGTS Details PDF |
| 0805CS-181EGTS Price |
Request Price & Lead Time Online or Email us: Info@ariat-tech.com |
| Technical Information of 0805CS-181EGTS | |||
|---|---|---|---|
| Manufacturer Part Number | 0805CS-181EGTS | Category | Inductors, Coils, Chokes |
| Manufacturer | Cyntec / Delta Electronics | Description | FIXED IND 180NH 400MA 640MOHM SM |
| Package / Case | 0805 | Quantity Available | 335315 pcs |
| Type | Drum Core, Wirewound | Tolerance | ±2% |
| Supplier Device Package | 0805 | Size / Dimension | 0.090" L x 0.071" W (2.29mm x 1.80mm) |
| Shielding | Unshielded | Series | 0805CS |
| Ratings | - | Q @ Freq | 50 @ 250MHz |
| Product Status | Active | Package / Case | 0805 (2012 Metric) |
| Package | Tape & Reel (TR) | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Material - Core | Ceramic |
| Inductance Frequency - Test | 100 MHz | Inductance | 180 nH |
| Height - Seated (Max) | 0.061" (1.55mm) | Frequency - Self Resonant | 870MHz |
| Features | - | DC Resistance (DCR) | 640mOhm |
| Current Rating (Amps) | 400 mA | Current - Saturation (Isat) | - |
| Base Product Number | 0805CS | ||
| Download | 0805CS-181EGTS PDF - DE.pdf | ||
Product Model
0805CS-181EGTS
Introduction
A fixed inductor from the 0805CS series designed for surface mount application in a variety of electronic circuits.
Brand and Manufacturer
delta-product-groups
Features
Wirewound construction with a ceramic core
Unshielded
Surface Mount
Product Performance
Inductance: 180 nH with ±2% Tolerance
Current Rating: 400 mA
DC Resistance (DCR): 640mOhm
Quality factor (Q) at frequency: 50 @ 250MHz
Self Resonant Frequency: 870MHz
Operating Temperature Range: -40°C to 125°C
Technical Specifications
Inductance Frequency Test: 100 MHz
Dimensions, Shape, and Packaging
090" L x 0.071" W (2.29mm x 1.80mm) Height - Seated (Max): 0.061" (1.55mm)
Packaged in Tape & Reel (TR)
Quality and Reliability
Robust construction ensuring stable performance over operating range
Product Advantages
High Q value at high frequency
Compact size suitable for space-sensitive applications
Product Competitiveness
Superior performance in high-frequency applications compared to similar inductors
Compatibility
Designed for seamless integration with standard SMT assembly processes
Standard Certification and Compliance
Complies with applicable industry standards for electronic components
Lifespan and Sustainability
Durable materials and construction for extended operational life under specified conditions
Actual Application Fields
Used in RF and signal processing circuits, high-frequency applications in telecommunications, and consumer electronics devices
